SECIFICATIONS
- Nominal diameter305mm / 12in
- Power rating30W
- Rated impedance8Ω or 16Ω
- Sensitivity100dB
- Chassis typePressed steel
- Magnet typeCeramic
- Magnet weight1.42kg / 50oz
- Voice coil diameter1.75in / 44mm
- Voice coil materialRound copper
- Frequency range75-5000Hz
- Resonance frequency, Fs85Hz
- DC resistance, Re6.7Ω and 13.1Ω
Mounting Information
- Cut-out diameter283mm / 11.1in
- Diameter309mm / 12.2in
- Magnet structure diameter156mm / 6.1in
- Mounting hole dimensions7.9mm / 0.31in Ø
- Mounting hole PCD297mm / 11.7in
- Number of mounting holes4
- Chassis depth (inc gasket)97mm / 3.79in
- Magnet depth38mm / 1.51in
- Overall depth135mm / 5.3in
- Unit weight4.7kg / 10.4lb
Lisainformatsioon
| Tootja | CELESTION |
|---|---|
| Mudel | G12H |
