SPECS
- Input Connections: Balanced XLR/Jack Combo (Channel 1-2), Balanced ¼” Jack (Channel 3-4)
- Output Connection: Balanced XLR (Main Out L-R), Stereo ¼” Jack (Phones)
- Channel 1-2 Functions: +48V Phantom Power, Impedance switch (Line/Hi-Z), 2-Band EQ (80Hz/12kHz +/-15dB), Effect Send Level, Pan Position, Channel Volume, Peak
- Led Indicator
- Channel 3-4 Functions: Impedance switch (+4/-10dB), 2-Band EQ (80Hz/12kHz +/-15dB), Effect Send Level, Pan Position, Channel Volume, Peak Led Indicator
- USB Player Buttons: Up/Rewind, Down/Forward, Play/Pause/Enter, Menu
- USB Player Functions: BT streaming, Music Player, Audio Recording, EQ-Curve Selection
- USB Drive Format: FAT32 format – max 64GByte
- Player File Formats: WAV, MP3, WMA, FLAC e streaming audio wireless BT
- Recorder File Format: MP3 (48kHz/16bit @ 128Kbps)
- Effect Functions: Echo Repetition Adjustment, Echo Delay Time Adjustment, Echo Level Adjustment
- Level Meter: 2x6 LED Meter
- Max Output Level: 3 Vrms
- Frequency Response: +/-0.5dB, 20Hz-20kHz
- Dynamic Range: 102dB
- THD+N @ 1kHz: =0.003%
- Stereo Crosstalk: 92dB
- Power Requirements: DC 5V, 1A
- Power Consumption: Max. 2.5W
- Size (WxDxH): 166 x 165 x 66 mm
- Packing Size (WxDxH): 300 x 208 x 87 mm
- Net Weight: 0.9 kg
- Gross Weight: 1.2 kg
Lisainformatsioon
| Tootja | SOUNDSATION |
|---|---|
| Mudel | MIOMIX202M |
