| PSR-F52 | ||
|---|---|---|
| Color/Finish | ||
| Body | Color | Black |
| Size/Weight | ||
| Dimensions | Width | 920 mm (36-1/4”) |
| Height | 73 mm (2-7/8”) | |
| Depth | 266 mm (10-1/2”) | |
| Weight | Weight | 2.8 kg (6 lbs. 3 oz.) (not including batteries) |
| Control Interface | ||
| Keyboard | Number of Keys | 61 |
| Touch Response | No | |
| Type | Organ-style | |
| Display | Type | 7-Segment LED |
| Panel | Language | English |
| Voices | ||
| Polyphony | Number of Polyphony (Max.) | 32 |
| Preset | Number of Voices | 136 Voices (including 41 World Voices) + 8 Drum Kits (including 5 World Drum Kits) |
| Effects | ||
| Types | Reverb | Yes (Fixed in Voice/Non editable) |
| Chorus | Yes (Fixed in Voice/Non editable) | |
| SOUND BOOST | Yes | |
| Functions | Dual/Layers | Yes (Fixed in Voice/Non editable) |
| Split | Yes (Fixed in Voice/Non editable) | |
| Panel Sustain | Yes | |
| Accompaniment Styles | ||
| Preset | Number of Preset Styles | 158 (including 75 World Styles) |
| Fingering | Smart Chord, Multi Finger | |
| Style Control | Fill-in, Intro/Ending (Auto/Manual), Sync Start | |
| Other Features | One Touch Setting (OTS) | Yes |
| Songs | ||
| Preset | Number of Preset Songs | 69 (including 1 Demo Song) |
| Functions | ||
| Lesson/Guide | Part Mute | |
| Overall Controls | Metronome | Yes |
| Tempo Range | 11 - 280 (Tap Tempo: 32 - 280) | |
| Transpose | -12 to 0, 0 to +12 | |
| Tuning | 427.0 - 440.0 - 453.0 Hz (approx. 0.2 Hz increments) | |
| Duo | Yes | |
| Miscellaneous | Other Functions | Volume Limit, Category Buttons |
| Storage and Connectivity | ||
| Connectivity | DC IN | 12V |
| Headphones | Stereo mini jack (PHONES/OUTPUT) | |
| Amplifiers and Speakers | ||
| Amplifiers | 2.5 W + 2.5 W | |
| Speakers | 8 cm x 2 | |
| Power Supply | ||
| Power Supply | AC Adaptor PA-130 or an equivalent recommended by Yamaha, or six "AA" size alkaline (LR6), manganese (R6) or Ni-MH rechargeable (HR6) batteries | |
| Power Consumption | 6 W (When using PA-130B AC adaptor) | |
| Auto Power Off Function | Off/5/10/15/30/60/120 (minutes) | |
| Accessories | ||
| Included Accessories | Music Rest | Yes |
| Song Book | Download from Yamaha web site | |
Lisainformatsioon
| Tootja | YAMAHA |
|---|---|
| Mudel | PSRF52 |
