12AX7 (ECC 83)
Impedance 1MΩ, max. voltage 6 Vpp
BALANCED DI OUT with transformer (GND switch)
DIGITAL OUTPUTS: RCA (with transformer) and TOSLINK with sampling rate switch 44.1/48/96KHz
GAIN RANGE -46 ÷ +23 dB
LOW: Level ±16 dB (Freq. 70Hz)
MID LOW: Level ±16 dB (Freq. 400 Hz)
MID HIGH : Level ±16 dB (Freq. 2.5 KHz)
HIGH: Level ±16 dB (Freq. 10 KHz)
3-WAY switch (FLAT / CUT / OLD)
GAIN | MASTER | DRIVE | BLEND
ON/OFF | DRIVE | BOOST
12VDC | 300mA (power supply included)
7.6” x 5” x 2.32” | 19.3cm x 12.7cm x 5.9cm
1.9 lbs | 840gr
Tootja | MARKBASS |
---|---|
Mudel | MBH120006Z |
