| CK61 | ||
|---|---|---|
| Control Interface | ||
| Keyboard | Number of Keys | 61 |
| Type | FSB keyboard, initial touch | |
| Voices | ||
| Tone Generation | Tone Generating Technology | AWM2, AWM (Organ Flutes) |
| Polyphony | Number of Polyphony (Max.) | 128 |
| Number of Live Set Sound | 160 (Preset Live Set Sounds: 80) | |
| Number of Voices | 363 | |
| Effects | ||
| Types | Insertion Effect | Drive 1 system (5 types) / Effect 2 systems (1: 36 types, 2: 36 types) |
| Delay | 4 types | |
| Reverb | 3 types | |
| Master EQ | 3-band | |
| Connectivity | ||
| Connectors | Line Out | [L/MONO]/[R] (6.3 mm, standard phone jacks, unbalanced) |
| A/D INPUT | [L/MONO]/[R] (6.3 mm, standard phone jacks) | |
| Headphones | [PHONES] (6.3 mm, standard stereo phone jack) | |
| Foot Controller | FOOT PEDAL [1]/[2] | |
| MIDI | MIDI [IN]/[OUT] | |
| USB | USB [TO HOST]/[TO DEVICE] | |
| DC IN | [DC IN] | |
| Functions | ||
| Bluetooth | Yes (Audio Input) * May not have this functionality depending on the country | |
| USB audio interface | [Sampling Frequency = 44.1 kHz] In: 2 channels (1 stereo channel) Out: 2 channels (1 stereo channel) | |
| Sound System | ||
| Amplifiers | 6 W × 2 | |
| Speakers | (12 cm × 6 cm) × 2, Switchable ON/OFF | |
| Other | ||
| Display | Full Dot LCD (128 x 64 dots) | |
| Included accessories | AC adaptor*, Owner’s Manual *May be included depending on your locale | |
| Power Supply | ||
| Power Supply | Adaptors | PA-150B or an equivalent recommended by Yamaha (Output: DC 12V, 1.5 A) |
| Batteries | Eight “AA” size alkaline (LR6) or Ni-MH rechargeable batteries | |
| Power Consumption | 11 W (When using PA-150B AC adaptor) | |
| Size/Weight | ||
| Dimensions | Width | 910 mm (35-13/16") |
| Height | 109 mm (4-5/16") | |
| Depth | 291 mm (11-7/16") | |
| Weight | Weight | 5.6 kg (12 lb 6 oz) (not including batteries) |
| Packing Box | Width | 1,100 mm (43-5/16") |
| Height | 240 mm (9-7/16") | |
| Depth | 410 mm (16-1/8") | |
Lisainformatsioon
| Tootja | YAMAHA |
|---|---|
| Mudel | CK61 |
