Size/Weight
|
|
Dimensions
|
Width
|
1,412 mm (55-9/16") [Polished finish: 1,418 mm (55-13/16")]
|
|
Height
|
1,041 mm (41") [Polished finish: 1,041 mm (41")]
|
|
Depth
|
465 mm (18-5/16") [Polished finish: 466 mm (18-3/8")]
|
|
Weight
|
Weight
|
67 kg (147 lb, 11 oz) [Polished finish: 69 kg (152 lb, 2
oz)]
|
|
Packing Box
|
Width
|
1,563 mm (61-17/32")
|
|
Height
|
621 mm (24-29/64")
|
|
Depth
|
740 mm (49-9/64")
|
|
Control Interface
|
|
Keyboard
|
Number of Keys
|
88
|
|
Type
|
GrandTouch-S™ Keyboard: wooden keys (white only), synthetic
ebony and ivory key tops, escapement
|
|
Touch Sensitivity
|
Soft2/Soft1/Medium/Hard1/Hard2/Fixed
|
|
88-key Linear Graded Hammers
|
-
|
|
Counterweight
|
-
|
|
Pedal
|
Number of Pedals
|
3: Damper (with half-pedal function), Sostenuto, Soft
|
|
GrandTouch Pedals
|
-
|
|
GP Response Damper Pedal
|
-
|
|
Functions
|
Sustain, Sostenuto, Soft, Glide, Style Start/Stop, Volume,
etc.
|
|
Display
|
Type
|
Depending on the Smart Device
|
|
Size
|
Depending on the Smart Device
|
|
Language
|
26 Languages (English, Japanese, Germany, French, Spanish,
etc.)
|
|
Panel
|
Language
|
English
|
|
Cabinet
|
|
Key Cover
|
Key Cover Style
|
Sliding
|
|
Music Rest
|
Yes
|
|
Music Clips
|
Yes
|
|
Voices
|
|
Tone Generation
|
Piano Sound
|
Yamaha CFX, Bösendorfer Imperial
|
|
Binaural Sampling
|
Yes (“CFX Grand” and “Bösendorfer” only)
|
|
Key-off Samples
|
Yes
|
|
Smooth Release
|
Yes
|
|
Virtual Resonance Modeling (VRM)
|
Yes
|
|
Grand Expression Modeling
|
Yes
|
|
Polyphony
|
Number of Polyphony (Max.)
|
256
|
|
Preset
|
Number of Voices
|
772 Voices + 47 Drum/SFX Kits
|
|
Compatibility
|
XG, GS, GM, GM2
|
|
Effects
|
|
Types
|
Reverb
|
65 Types
|
|
Master EQ
|
5 Types
|
|
Vocal Harmony
|
44 Types
|
|
Intelligent Acoustic Control (IAC)
|
Yes
|
|
Stereophonic Optimizer
|
Yes
|
|
Functions
|
Dual/Layers
|
Yes
|
|
Split
|
Yes
|
|
Accompaniment Styles
|
|
Preset
|
Number of Preset Styles
|
495
|
|
Style Control
|
INTRO x 1, ENDING x 1, MAIN x 4, FILL IN x 4
|
|
Other Features
|
Music Finder
|
-
|
|
One Touch Setting (OTS)
|
-
|
|
Songs
|
|
Preset
|
Number of Preset Songs
|
403
|
|
Recording
|
Number of Songs
|
Depending on the Smart Device
|
|
Number of Tracks
|
16
|
|
Data Capacity
|
Depending on the Smart Device
|
|
Compatible Data Format
|
Playback
|
SMF (Format 0 & 1), XF
|
|
Recording
|
SMF (Format 0)
|
|
Functions
|
|
Piano Room
|
Yes
|
|
Lesson/Guide
|
Lesson/Guide
|
Correct Key, Any Key, Karao-Key, Your Tempo
|
|
Guide Lamp
|
Stream Lights (4 steps)
|
|
USB Audio Recorder
|
Recording
|
Depending on the Smart Device
|
|
Playback
|
Supported format by the Smart Device
|
|
USB Audio
|
Time Stretch
|
Yes
|
|
Pitch Shift
|
Yes
|
|
Vocal Cancel
|
Melody Suppressor
|
|
Overall Controls
|
Metronome
|
Yes
|
|
Tempo Range
|
5 – 500, Tap Tempo
|
|
Transpose
|
-12 - 0 - 12
|
|
Tuning
|
414.8 – 440.0 – 466.8 Hz (0.2 Hz increments)
|
|
Scale Type
|
9
|
|
Audio to Score
|
Yes
|
|
Registration Memory
|
Yes
|
|
Bluetooth
|
Audio/MIDI (varies by country)
|
|
Storage and Connectivity
|
|
Storage
|
External Drives
|
Depending on the Smart Device
|
|
Connectivity
|
Headphones
|
Standard stereo phone jack (× 2)
|
|
Microphone
|
Mic/Line In, Input Volume
|
|
MIDI
|
IN, OUT, THRU
|
|
AUX IN
|
Stereo Mini jack
|
|
AUX OUT
|
Standard phone jack (R, L/L+R)
|
|
AUX Pedal
|
Yes
|
|
USB TO DEVICE
|
Yes
|
|
DC IN
|
Yes
|
|
Amplifiers and Speakers
|
|
Amplifiers
|
(50 W + 50 W) × 2
|
|
Speakers
|
(16 cm + 8 cm) × 2
|
|
Power Supply
|
|
Power Consumption
|
60 W
|
|
Auto Power Off
|
Yes
|
|
Accessories
|
|
Accessories
|
Owner’s Manual, USB cable(Type-C to Type-C), Online Member
Product Registration, Power cord
|
