Size/Weight
|
Dimensions
|
Width
|
992 mm (39-1/16”)
|
|
Height
|
136 mm (5-3/8”)
|
|
Depth
|
404 mm (15-7/8”)
|
|
Weight
|
Weight
|
7.3 kg (16 lb, 1 oz) (not including batteries)
|
|
Packing Box
|
Width
|
1068 mm (42-1/16")
|
|
Height
|
216 mm (8-1/2")
|
|
Depth
|
500 mm (19-11/16")
|
|
Control Interface
|
Keyboard
|
Number of Keys
|
61
|
|
Type
|
Organ-Style
|
|
Touch Response
|
Yes (Soft, Medium, Hard, Off)
|
|
Display
|
Type
|
LCD
|
|
Backlight
|
Yes
|
|
Language
|
English
|
|
Panel
|
Language
|
English
|
|
Other Controllers
|
Pitch Bend
|
Yes
|
|
Modulation
|
Yes
|
|
Art. Switches
|
Yes
|
|
Control Knobs
|
2
|
|
Voices
|
Tone Generation
|
Tone Generating Technology
|
AWM Stereo Sampling
|
|
Polyphony
|
Number of Polyphony (Max.)
|
64
|
|
Preset
|
Number of Voices
|
890 (352 Voices + 40 Drum/SFXKits + 40 Arpeggio Voices +
458 XGlite Voices)
|
|
Featured Voices
|
19 S.Art Lite Voices
|
|
Compatibility
|
GM
|
Yes
|
|
XGlite
|
Yes
|
|
Accompaniment Styles
|
Preset
|
Number of Preset Styles
|
345
|
|
Fingering
|
Multi Finger, Smart Chord
|
|
Style Control
|
ACMP ON/OFF, SYNC START, SYNC STOP, START/STOP,
INTRO/ENDING/rit., MAIN A, MAIN B, TRACK ON/OFF
|
|
Other Features
|
One Touch Setting (OTS)
|
Yes
|
|
Auto Chord Play
|
100 Chord Progressions + 10 USER Chord Progressions
|
|
Expandability
|
Expansion Style
|
10
|
|
Compatibility
|
Style File Format (SFF)
|
|
Effects
|
Types
|
DSP
|
DSP1: 41 types + DSP2: 12 types
|
|
Motion Effect
|
57 types
|
|
Reverb
|
15 types
|
|
Chorus
|
7 types
|
|
Master EQ
|
5 types
|
|
Functions
|
Dual/Layers
|
Yes
|
|
Split
|
Yes
|
|
Melody Suppressor
|
Yes
|
|
Harmony/Echo
|
26 types
|
|
Arpeggio
|
164 types
|
|
Songs
|
Preset
|
Number of Preset Songs
|
2
|
|
Recording
|
Number of Songs
|
10
|
|
Number of Tracks
|
6 (5 Melody + 1 Style)
|
|
Data Capacity
|
Approx. 19,000 notes (total for all 10 Songs)
|
|
Compatible Data Format
|
Playback
|
SMF (Formats 0 & 1)
|
|
Recording
|
Original File Format (SMF 0 conversion function)
|
|
USB Audio Recorder
|
Recording Time (max.)
|
80 minutes (approx. 0.9 GB) per Song
|
|
Format
|
Playback
|
WAV (44.1 kHz, 16-bit, stereo)
|
|
Recording
|
WAV (44.1 kHz, 16-bit, stereo)
|
|
Quick Sampling
|
Sampling Type
|
Oneshot, Loop
|
|
Samples (Preset/User)
|
4
|
|
Sampling Time
|
Approx. 9.6 sec
|
|
Sampling Sources
|
AUX IN, MIC INPUT, USB audio interface, WAV format files
|
|
Sampling Format
|
Original File Format (16-bit, stereo)
|
|
Sampling Rate
|
44.1 kHz
|
|
Functions
|
USB audio interface
|
44.1 kHz, 16-bit, stereo
|
|
Registration
|
Number of Buttons
|
4 (x 8 banks)
|
|
Control
|
Freeze
|
|
Overall Controls
|
Metronome
|
Yes
|
|
Tempo Range
|
11 – 280
|
|
Transpose
|
-12 – 0 – +12
|
|
Tuning
|
427.0 – 440.0 – 453.0 Hz (approx. 0.2 Hz increments)
|
|
Octave Button
|
Yes
|
|
Scale Type
|
5
|
|
Miscellaneous
|
PIANO Button
|
Yes
|
|
Looper
|
Yes
|
|
Megaboost
|
2 steps (approx. +3 dB, and +6 dB)
|
|
Storage and Connectivity
|
Storage
|
Internal Memory
|
Approx. 1.72 MB
|
|
External Drives
|
USB flash drive
|
|
Connectivity
|
DC IN
|
16 V
|
|
AUX IN
|
Stereo mini jack × 1
|
|
Headphones
|
Standard stereo phone jack × 1
|
|
Foot Switch
|
Yes (Sustain, Arpeggio Hold, Sustain+Arpeggio Hold,
Articulation)
|
|
Expression Pedal
|
Yes
|
|
USB TO DEVICE
|
Yes (USB Type-A)
|
|
USB TO HOST
|
Yes (USB Type-C™)
|
|
LINE OUT
|
Standard stereo phone jacks: L/L+R, R
|
|
Microphone
|
Standard stereo phone jack x 1
|
|
Sound System
|
Amplifiers
|
12 W x 2
|
|
Speakers
|
12 cm x 2
|
|
Power Supply
|
Power Supply
|
Adaptors
|
PA-300C (Output : DC 16 V, 2.4 A)
|
|
Batteries
|
Six “AA” size alkaline (LR6), manganese (R6) or Ni-MH
rechargeable batteries
|
|
Power Consumption
|
13 W (When using PA-300C AC adaptor)
|
|
Auto Power Off Function
|
Yes (Disabled/5/10/15/30/60/120 minutes)
|
|
Accessories
|
Included Accessories
|
Owner’s Manual, Music Rest, AC adaptor PA-300C*, Power
Cord* (* May not be included depending on your area. Check
with your Yamaha dealer.)
|
