Weight | 7.5 kg |
Dimensions (LxDxH) | 27 x 18 x 28 cm |
Frequency Response (@ +/-3dB) | 55 to 20kHz |
Sensitivity (1W/1m) @1 kHz | 92.5 dB |
Power | 70 W pure analog power amp |
SPL Max | 108 dB |
Speakers | Coaxial 1” dome tweeter, 5.5” woofer |
Construction | 12mm birch BB laminated |
System - Format | Two way, bi-amplified - Bass reflex |
Mic In connector | XLR |
Mic In sensitivity | -52 dB |
Mic In impedance | 4.7 kΩ |
Instrument In connector | 1/4" jack unbalanced |
Instrument In sensitivity | -47 dB |
Instrument In impedance | 820 kΩ |
Insert | On master |
Line Out connector | 1/4" jack |
Line Out level | 0 dBu |
Line Out impedance | 200 Ω |
DI Out connector | XLR |
DI Out level | -15 dBu |
DI Out impedance | 200 Ω |
Phantom Power (nominal) | 24 VDC |
Stat Power (10 VDC) | Yes |
Effect | Spring-type digital reverb |
Preamp | Class-A, no negative feedback, no integrated circuits |
Производитель | SCHERTLER |
---|---|
Модель | GiuliaXwood |
