Weight | 12.5 kg |
Dimensions (LxDxH) | 32.4 x 29.7 x 38 cm |
Frequency Response (@ +/-3dB) | 40 to 20 kHz |
Sensitivity (1W/1m) @1 kHz | 95 dB |
Power | 240 W pure analog power amp |
SPL Max | 117 dB |
Speakers | 1” dome tweeter, 8” woofer |
Construction | 12 mm birch BB laminated |
System - Format | Two way, bi-amplified - Bass reflex |
Mic In connector | XLR |
Mic In sensitivity | -52 dB |
Mic In impedance | 4.7 kΩ |
Instrument In connector | 1/4" jack unbalanced |
Instrument In sensitivity | -47 dB |
Instrument In impedance | 820 kΩ |
Stereo In connector | 1/8" jack stereo |
Stereo In sensitivity | -10 dBu |
Stereo In impedance | 40 kΩ |
Insert | On master |
Line Out connector | 1/4" jack |
Line Out level | 0 dBu |
Line Out impedance | 200 Ω |
DI Out connector | XLR |
DI Out level | -∞ to +6 dBu |
DI Out impedance | 180 Ω |
Aux Out connector | 1/4" jack unbalanced |
Aux Out level | 0 dBu |
Aux Out impedance | 200 Ω |
Phantom Power (nominal) | 24 VDC |
Stat Power (10 VDC) | Yes |
Effect | Spring-type digital reverb with decay |
Preamp | Class-A, no negative feedback, no integrated circuits |
Stand mounting | Flange mount ø 36 mm, h=102 mm |
Производитель | SCHERTLER |
---|---|
Модель | JamXwood |
