System Type: 2-way active ported loudspeaker
Drivers:
- Low-Frequency: 15.0” (381 mm) driver, 2.0” (51 mm) voice coil
- High-Frequency: 1.0” (25 mm) titanium-diaphragm compression driver, 1.0” (25 mm) voice coil
Amplifier: 700 watts (peak), 350 (continuous),
Class D power
Horn Coverage: 90º horizontal x 60º vertical
(nominal)
Frequency Response: 65 Hz – 20 kHz (-3 dB)
Crossover Frequency: 2.2 kHz
Max SPL: 121 dB @ 1 m
Equalization: Contour switch with low- and
high-frequency +3 dB boost
Connectors:
- (1) XLR/TRS 1/4” (6.35 mm) balanced input (Line/Mic)
- (1) XLR output (Link)
- (1) IEC power cable input
Controls: Power switch, volume control knob,
contour switch, ground-lift switch
Indicators: (2) power LEDs (1 front panel, 1
rear panel), clip limiter LED
Power:
- Connection: IEC
- Voltage: 100–120 V~, or 220–240 V~; 50/60 Hz
- Fuse: 100–120V T6.3AL AC250V or 220–240V T3.15AL AC250V
- Consumption: 350 W
Protection: Thermal, overload analog
limiter/compressor
Enclosure: Injection-molded polypropylene,
multi-angle for main or monitor applications, metal grille,
rubber feet, 2 handles (both sides)
Mounting/Installation: Standard 36 mm pole
socket, wedge monitor
Dimensions (height x width x depth):
- 24.9” x 15.2” x 14.6”
- 634 x 386 x 371 mm
Weight:
- 31.7 lb
- 14.4 kg
Дополнительная информация
| Производитель | ALTO |
|---|---|
| Модель | TX315 |
