SPECIFICATIONS
- Nominal Input Level: -20 dBu
- Input Impedance: 1 M ohm
- Nominal Output Level: -20 dBu
- Output Impedance: 1 k ohm
- Recommended Load Impedance: 10 k ohms or greater
- Bypass: Buffered bypass
Controls
- SUSTAIN knob
- ATTACK knob
- TONE knob
- LEVEL knob
- Pedal switchIndicatorCHECK indicator (Serves also as battery check indicator)
Connectors
- INPUT jack: 1/4-inch phone type
- OUTPUT jack: 1/4-inch phone type
- DC IN jack
Power Supply: Carbon-zinc battery (9V, 6F22) or Alkaline battery (9V, 6LR61)AC adaptor (PSA series: sold separately)
Current Draw: 20 mA
Expected battery life under continuous useCarbon: Approx. 10.5 hours. Alkaline: Approx. 26 hours
*These figures will vary depending on the actual conditions of use.
Accessories: Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information") Dry battery/9 V type (6F22)
Options (sold separately): PSA series AC adaptor
SIZE AND WEIGHT
- Width73 mm/2-7/8 inches
- Depth129 mm/5-1/8 inches
- Height59 mm/2-3/8 inches
- Weight380 g/14 oz
Дополнительная информация
| Производитель | BOSS |
|---|---|
| Модель | CS3 |
