Size/Weight
|
|
Dimensions
|
Width
|
1,450 mm [57-1/16"] Polished finish: 1,455 mm [57-5/16"]
|
|
Height
|
927 mm [36-1/2"] (with music rest raised: 1,091 mm
[42-15/16"]) Polished finish: 930 mm [36-5/8"] (with music
rest raised: 1,092 mm [43-0"])
|
|
Depth
|
460 mm [18-1/8"] Polished finish: 460 mm [18-1/8"]
|
|
Weight
|
Weight
|
60 kg [132 lb, 4 oz] Polished finish: 63 kg [138 lb, 14 oz]
|
|
Dimensions of Packing Box
|
W x H x D
|
1,571 mm x 639 mm x 569 mm [61-7/8" x 25-3/16" x 22-3/8"]
|
|
Control Interface
|
|
Keyboard
|
Number of Keys
|
88
|
|
Type
|
GrandTouch-S™ keyboard: wooden keys (white only), synthetic
ebony and ivory key tops, escapement
|
|
Touch Sensitivity
|
Hard2, Hard1, Medium, Soft1, Soft2, Fixed
|
|
88-key Linear Graded Hammers
|
-
|
|
Counterweight
|
-
|
|
Pedal
|
Number of Pedals
|
3: Damper (with half-pedal function), Sostenuto, Soft
|
|
GrandTouch Pedals
|
Yes
|
|
Assignable Functions
|
Sustain (Switch), Sustain (Continuous), Sostenuto, Soft,
Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor,
Song Play/Pause
|
|
Display
|
Type
|
Full Dots LCD
|
|
Language
|
English, Japanese
|
|
Panel
|
Type
|
Buttons
|
|
Language
|
English
|
|
Cabinet
|
|
Key Cover Style
|
Sliding
|
|
Music Rest
|
Yes
|
|
Music Braces
|
Yes
|
|
Voices
|
|
Tone Generator
|
Piano Sound
|
Yamaha CFX, Bösendorfer Imperial
|
|
Binaural Sampling
|
Yes (“CFX Grand” and “Bösendorfer” only)
|
|
Virtual Resonance Modeling (VRM)
|
Yes
|
|
Grand Expression Modeling
|
Yes
|
|
Polyphony
|
Number of Polyphony (Max.)
|
256
|
|
Preset
|
Number of Voices
|
38
|
|
Compatibility
|
-
|
|
Effects
|
|
Types
|
Reverb
|
7 types
|
|
Chorus
|
3 types
|
|
Brilliance
|
7 types + User
|
|
Insertion Effect
|
12 types
|
|
Intelligent Acoustic Control (IAC)
|
Yes
|
|
Stereophonic Optimizer
|
Yes
|
|
Functions
|
Dual/Layers
|
Yes
|
|
Split
|
Yes
|
|
Duo
|
Yes
|
|
Songs
|
|
Preset
|
Number of Preset Songs
|
23 Voice Demo + 50 Classics + 303 Lesson Songs
|
|
MIDI Recording
|
Number of Songs
|
250
|
|
Number of Tracks
|
16
|
|
Data Capacity
|
Approx. 500 KB/Song (approx. 22,000 notes)
|
|
Audio Recording (USB flash drive)
|
Recording Time (max.)
|
80 minutes/Song
|
|
Compatible Data Format
|
Playback
|
SMF (Format 0, Format 1), WAV (44.1 kHz, 16-bit, stereo)
|
|
Recording
|
SMF (Format 0), WAV (44.1 kHz, 16-bit, stereo)
|
|
Functions
|
|
Piano Room
|
Yes
|
|
Rhythm
|
Number of Rhythms
|
20
|
|
Overall Controls
|
Metronome
|
Yes
|
|
Tempo Range
|
5 – 500
|
|
Transpose
|
−12 – 0 – +12
|
|
Tuning
|
414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments)
|
|
Scale Type
|
7 types
|
|
USB Audio Interface
|
44.1 kHz, 24 bit, stereo
|
|
Bluetooth
|
Audio, MIDI (varies by area)
|
|
Storage and Connectivity
|
|
Storage
|
Internal Memory
|
Total maximum size approx. 1.4 MB
|
|
External Drives
|
USB flash drive
|
|
Connectivity
|
Headphones
|
Standard stereo phone jack (× 2)
|
|
AUX IN
|
Stereo mini jack
|
|
AUX OUT
|
Standard phone jack (L/L+R, R)
|
|
USB TO DEVICE
|
Type A
|
|
USB TO HOST
|
Type B
|
|
DC IN
|
24 V
|
|
Amplifiers and Speakers
|
|
Amplifiers
|
(45 W + 45 W) × 2
|
|
Speakers
|
(16 cm with diffuser + 8 cm with diffuser) × 2
|
|
Power Supply
|
|
AC Adaptor
|
PA-500
|
|
Power Consumption
|
30 W (When using PA-500 AC adaptor)
|
|
Auto Power Off
|
Yes
|
|
Accessories
|
|
Included Accessories
|
Owner’s Manual, “50 Classical Music Masterpieces” Music
Book, Online Member Product Registration, Power cord*/AC
adaptor* (PA-500) *Varies by area
|
|
Separately Sold Accessories
|
Headphones (HPH-150, HPH-100, HPH-50), Pedal unit (FC35),
AC adaptor (PA-500), USB wireless LAN adaptor (UD-WL01)
|
