TECHNICAL SPECIFICATION
GENERAL
- Model: ST20C
- Range: Studio
- Technology: Valve
- Channels: 1 with 2 voicings
ELECTRONICS
- Output wattage: 20W (with power reduction option to 5W)
- Outputs: DI output and 5 x 1/4” speaker outputs (16Ω load / 8Ω load / 4Ω load)
- Inputs: 4 x 1/4" jack instrument inputs (high/low sensitivity)
- Controls: Treble, Middle, Bass and Presence
- Effects: None
- Effects loop: Yes, send/return
SPEAKERS
- Speaker configuration: 1x12”
- Power handling: 65W
- Speaker model: Celestion G12M-65 Creamback (16Ω, 65W)
- Unit impedance: 16Ω
VALVES
- Preamp valves: 2 x ECC83, 1 x ECC83 (phase splitter)
- Power amp valves: 2 x 5881
ACCESSORIES
- Cable: Detachable power cable included
DIMENSIONS (INCLUDING FEET AND HANDLE)
- Weight: 17.8kg / 39.2lbs
- Width: 500mm / 19.7"
- Height: 460mm / 18.1"
- Depth: 265mm / 10.4"
Дополнительная информация
| Производитель | MARSHALL |
|---|---|
| Модель | ST20CE |
