RU-8012DB
- Frequency Preparation PLL Synthesized Control
- Carrier Frequency Range 470~960 MHz
- Frequency Setting Ultrasonic / REMOSET (Transmit)
- Receiving Mode Antenna Diversity
- Bandwidth 36MHz
- S/N Ratio >105dB(A)
- T.H.D <0.6%@1KHz
- Sensitivity -95dBm,S/N>80dB
- Rejection Ratio >80 dB
- Frequency Response 50Hz~16KHz±2dB
- Antenna Type BNC Socket
- Antenna Booster Power DC12~15V/100mA
- Display LCD
- Display Contents Group, Channel, Frequency, Battery Level, Antenna A/B, Mute Display, AF Meter,
- RF Meter, Frequency Scan, Audio Level, Volume
- Controls Power ON/OFF, Group, Channel, Frequency, Mute Display, Key Lock, Volume, Output
- Attenuation(XLR), Frequency Scan(ON/OFF)
- Audio Output Level Ref/ ±22.5KHz Dev@1KHz Tone
- ψ6.3 Phone Jack/ -10dBV
- XLR Jack/ -4dBV(Line) ˴ -24dBV(MIC)
- Audio Output Impedance 600Ω
- Squelch Pilot Tone & Noise Mute
- Output Connector 2 independent balanced XLR and 2 Ø6.3mm unbalanced.
- Power Supply DC12~15V/500mA
- Dimension (mm) 212.3mm(W)* 38.3mm(H)* 144mm(D)
- Notes Actual product specifications may vary depending on model and region
RU-850LTH
- Frequency Preparation PLL Synthesized Control
- Carrier Frequency Range 470~960MHz
- Frequency Setting REMOSET U(Receive)
- RF Outputs Low / High
- Stability <±10KHz@Fc
- Frequency Deviation ±48KHz
- Spurious Emissions <-50dBc
- Function Mute, Auto Power Off, Sensitivity Adjust, Low Battery
- Display LCD+LED
- Controls Power, Mute, Group, Channel,
- Frequency, Gain Adjust, Auto Power Off, Key
- Lock
- Battery UM3, AA x2
Дополнительная информация
| Производитель | JTS |
|---|---|
| Модель | RU8012DB/RU850LTD |
