| Output Power | 200 W |
| Charge Port | 5V, 1A |
| Mic Inputs 1-2 |
Connector: XLR / 1/4” TRS Combo Input Connector Dynamic Range: 108 dB (A-weighted) THD+N: <0.01% Noise EIN: >-110 dB (A-weighted) Maximum Input Level: +1.5 dBu Gain Range: 50 dB Frequency Response: 20 Hz – 20 kHz (+/- 0.1 dB) Input Impedance: 600 Ω |
| Line Inputs 1-2 |
Connector: XLR / 1/4” TRS Combo Input Connector Dynamic Range: 108 dB (A-weighted) THD+N: <0.01% Maximum Input Level: +16 dBu Gain Range: 24 dB Frequency Response: 20 Hz – 20 kHz (+/- 0.1 dB) Input Impedance: 20 kΩ |
| Instrument Inputs 1-2 |
Connector: XLR / 1/4” TRS Combo Input Connector Dynamic Range: 108 dB (A-weighted) THD+N: <0.02% Gain Range: 24 dB Frequency Response: 20 Hz – 20 kHz (+/- 0.1 dB) Maximum Input Level: +6 dBu Input Impedance: 1 mΩ |
| Channel EQ |
EQ Configuration: Channels 1 and 2 have independent 2-band
shelving EQs High EQ Filter Type: 12 dB/octave shelving filter High EQ Cutoff Frequency: 12 kHz High EQ Gain/Attenuation: +/-15 dB Low EQ Filter Type: 12 dB/octave shelving filter Low EQ Cutoff Frequency: 80 Hz Low EQ Gain/Attenuation: +/-15 dB |
| Aux Inputs |
Connector: 1/8” (3.5 mm) TRS Input Connector Frequency Response: 20 Hz – 20 kHz (+/- 0.1 dB) Maximum Input Level: +12 dBu Input Impedance: 20 kΩ |
| Line Output |
Connector: 1/4” (6.35 mm) TRS Output Connector Frequency Response: 20 Hz – 20 kHz (+/- 0.1 dB) Output Level: Fixed +10 dBu Input Impedance (unbalanced): 100 Ω |
| Amp/Drivers |
Frequency Response: 60 Hz – 20 kHz Max SPL: 110 dB Power Amp: 100 W RMS mono-bridged LF Driver: 8.0” 203 mm woofer HF Drivers: (2) 1.0” / 25 mm tweeters Side Drivers: (2) 3.0” / 76 mm drivers |
| Bluetooth Specifications |
Profile: A2DP, AVRCP Version: 5.0 Frequency: 2402 – 2480 MHz Range: Up to 100 feet / 30.5 meters* |
| Battery |
Type: lead-acid battery Capacity: 12V, 7A, 84 Wh Life: Up to 100 hours Charging Time: 10 hours |
| USB-A Charging |
Front USB Port: 5V, 1A Top USB Port: 5V, 2.2A |
| Power |
Connection: IEC Voltage: 100–240 VAC, 50/60 Hz, 120 W |
|
Dimensions (height x width x depth) |
19.4” x 10.4” x 15.1” / 493 x 383.6 x 266.6 mm |
| Weight |
22.9 lbs. / 10.4 kg |
Дополнительная информация
| Производитель | ALTO |
|---|---|
| Модель | UBERFX2 |
