PRESONUS Studio 1824C Audio Interface 2777706402

PreSonus® was a pioneer in high-channel-count audio interfaces and has spent the last 20 years creating the best audio interfaces for recording large sessions. Building on this legacy, the Studio 1824c provides amazing sound-quality with eight of PreSonus' lauded XMAX analog mic preamps onboard and pristine 24-bit 192 kHz conversion. Add two low-noise instrument preamps, balanced line-level inputs, and an ADAT input to add 8 more channels whenever you need them, and you have an audio interface ready to record just about any session.

When you have the right tools, any job is easier and faster to finish. High-quality converters and PreSonus' professional-grade XMAX mic preamps capture complex musical harmonics smoothly and naturally, with no audible distortion. XMAX mic preamps deliver incredibly high headroom, deep lows, smooth highs, and a rich overall sound, so you'll hear every breath, transient, and detail in your recordings. Professional input and output metering let you keep an eye on your levels. A flexible DSP mixer lets you create four discrete near-zero-latency monitor mixes. Front-panel Mute, Mono, and level controls let you work with your main mix.

Whether you're upgrading your studio or building a new space for your band to record, the Studio 1824c has you covered with superior mic preamps, expandable inputs, and powerful, easy-to-use onboard monitor mixing to give you the world-class results you want.

Up to 18 inputs/20 outputs simultaneously (8x8 at 192 kHz)
2 mic/instrument/line inputs with XMAX Class A mic preamps
6 mic/line inputs with XMAX Class A mic preamps
8 channels of ADAT Optical I/O (4 channels at 96 kHz)
2 balanced ¼-inch TRS main outputs and 8 balanced ¼-inch TRS line outputs for monitor mixing, all DC coupled for sending control voltages
2 stereo headphone outputs with individual level controls
Stereo S/PDIF digital I/O and MIDI In/Out
18x8 onboard DSP monitor mixer
Front-panel level controls plus Mono and Mute buttons for the main outputs
True +48V phantom power for condenser microphones (global)
10 ladder-style 8-LED level meters (8 input, 2 main output)
24-bit resolution, 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
USB-C to USB-C and USB-C to USB-A cables included for compatibility with most computers
Includes Studio One Artist®, Studio Magic Software Suite, and Ableton® Live Lite

425,00 €

Доступность: Есть в наличии

Производитель: PRESONUS

Модель: 2777706402

Арт.: INV08850

Кол-во:

Есть в наличии

Electronics

INPUTS: Eight - Eight Combo Mic/Instrument/Line Inputs (XLR Female Balance, 1/4" TS Female Unbalanced (Inst))
HEADPHONE JACK: 1/8" TRS Active Stereo
LINE OUT: Four - 1/4" TRS Balanced, DC Coupled
CONNECTIVITY: USB-C®
VOLTAGE: 220-240V EU
PHANTOM POWER: 48V (>10 mA per Channel)

Performance

DIGITAL AUDIO BIT DEPTH: 24 Bit
DIGITAL AUDIO DYNAMIC RANGE: 114 dB

Inputs

INSTRUMENT INPUTS DYNAMIC RANGE: 112 dB (A-Weighted, Minimum Gain)
INSTRUMENT INPUTS FREQUENCY RESPONSE: 20 Hz - 20 kHz (Minimum Gain)
INSTRUMENT INPUTS GAIN RANGE: 80 dB
INSTRUMENT INPUTS MAXIMUM LEVEL: +15 dBu (Unbalanced, Minimum Gain)
LINE INPUTS DYNAMIC RANGE: 112 dB (A-Weighted, Minimum Gain)
LINE INPUTS FREQUENCY RESPONSE: 20 Hz - 20 kHz (Unity Gain)
LINE INPUTS GAIN RANGE: 40 dB
LINE INPUTS IMPEDANCE: 10 kΩ
LINE INPUTS MAXIMUM LEVEL: +21 dBu (Balanced, Minimum Gain)
LINE INPUTS TOTAL HARMONIC DISTORTION: 0.005% (1 kHz, +18 dBu, Minimum Gain)
MICROPHONE INPUT CONNECTION TYPE: Combo Locking XLR Mic - 1/4” TRS Line
MICROPHONE PREAMP DYNAMIC RANGE: 110 dB (A-Weighted, Minimum Gain)
MICROPHONE PREAMP EQUIVALENT INPUT NOISE: -128 dBu (A-Weighted, 20 kHz BW, Rs=150Ω, Maximum Gain)
MICROPHONE PREAMP FREQUENCY RESPONSE: 20 Hz - 20 kHz (Unity Gain)
MICROPHONE PREAMP GAIN CONTROL RANGE: 80 dB
MICROPHONE PREAMP INPUT IMPEDANCE: 1.4 kΩ
MICROPHONE PREAMP MAXIMUM INPUT LEVEL: +16 dBu, Minimum Gain
MICROPHONE PREAMP TOTAL HARMONIC DISTORTION: 0.005% (1 kHz, 0dBu, Unity Gain)

Outputs

HEADPHONE OUTPUTS DYNAMIC RANGE: 103 dB (A-weighted, 1 kHz, Unity Gain)
HEADPHONE OUTPUTS FREQUENCY RESPONSE: 20 Hz - 20 kHz (Unity Gain)
HEADPHONE OUTPUTS IMPEDANCE WORKING RANGE: 32Ω to 600Ω
HEADPHONE OUTPUTS MAXIMUM OUTPUT: 150 mW/Channel (60Ω Load)
HEADPHONE OUTPUTS TOTAL HARMONIC DISTORTION: 0.250% (1 kHz, 150 mW, Unity Gain)
LINE OUTPUTS CONNECTION TYPE: 1/4" TRS Female
MAIN AND LINE OUTPUTS DYNAMIC RANGE: 108 dB (A-Weighted, Unity Gain)
MAIN AND LINE OUTPUTS FREQUENCY RESPONSE: 20 Hz - 20 kHz (Unity Gain)
MAIN AND LINE OUTPUTS MAXIMUM LEVEL: +18 dBu (Balanced)
MAIN AND LINE OUTPUTS TOTAL HARMONIC DISTORTION: 0.004% (1 kHz, -1 dBFS, Unity Gain)
MAIN OUTPUTS CONNECTION TYPE: 1/4" TRS Female

Hardware

MIDI IO: Dual 5-Pin Female DIN

Measurements

DIMENSIONS: 1.80x19.00x5.50 IN
SHIPPING WEIGHT: 4.80 LB
PRODUCT DEPTH: 5.5" (140 mm)
PRODUCT HEIGHT: 1.75" (44.45 mm)
PRODUCT WIDTH: 19" (483mm)
SHIPPING LENGTH: 5.50 IN
SHIPPING HEIGHT: 1.80 IN
SHIPPING WIDTH: 19.00 IN

Miscellaneous

COMMODITY CODE: 8517620000
POWER CABLE: 12 VDC, External Power Supply
SUPPORTED SAMPLE RATES: 44.1, 48, 88.2, 96, 176.4, 192 kHz (kHz)
