Size/Weight | ||
---|---|---|
Dimensions | Width | 1260 mm (49-5/8”) |
Height | 104 mm ( 4-1/8”) | |
Depth | 260 mm (10-1/4”) | |
Weight | Weight | 6.0 kg (13 lbs., 4 oz.) (batteries not included) |
Control Interface | ||
Keyboard | Number of Keys | 76 |
Type | Box Type (Graded Soft Touch) | |
Touch Response | Yes (Soft, Medium, Hard, Fixed) | |
Panel | Language | English |
Voices | ||
Tone Generation | Tone Generating Technology | AWM Stereo Sampling |
Polyphony | Number of Polyphony (Max.) | 64 |
Preset | Number of Voices | 15 |
Effects | ||
Types | Reverb | 6 types |
Sound Boost | Yes | |
Functions | Dual/Layers | Yes |
Songs | ||
Preset | Number of Preset Songs | 15 Voice Demo Songs + 10 Piano Songs |
Recording | Number of Songs | 1 |
Number of Tracks | 1 | |
Data Capacity | Approx. 7,000 notes | |
Functions | ||
Overall Controls | Metronome | Yes |
Tempo Range | 32 – 280 | |
Transpose | −6 – 0 – +6 | |
Tuning | 414.8 Hz – 440.0 Hz – 466.8 Hz (approx. 0.2 Hz increments) | |
Storage and Connectivity | ||
Connectivity | DC IN | 12V |
Headphones | Standard stereo phone jack (PHONES/OUTPUT) | |
Sustain Pedal | Yes (Half-Damper compatible with optiona FC3A) | |
USB TO HOST | Yes (MIDI/AUDIO) | |
Amplifiers and Speakers | ||
Amplifiers | 6 W ×2 | |
Speakers | (12 cm × 8 cm) ×2 | |
Power Supply | ||
Power Supply | AC Adaptor PA-150 or an equivalent recommended by Yamaha, or six "AA" size alkaline (LR6), manganese (R6) or Ni-MH rechargeable (HR6) batteries | |
Power Consumption | 6.0 W (When using PA-150 AC adaptor) | |
Auto Power Off | Yes | |
Accessories | ||
Accessories | Owner’s Manual, Online Member Product Registration, Music rest, AC adaptor: PA-150 or an equivalent recommended by Yamaha *May not be included depending on your area. Check with your Yamaha dealer. |
Производитель | YAMAHA |
---|---|
Модель | NP35B |
