INPUTS
- INPUT impedance: 1 Mohm, max. voltage: 9 Vpp
- RETURN impedance: 22 Kohm, max. voltage: 10 Vpp
CONTROLS
- GAIN –46 dB to +23 dB range
- LINE OUT level control on front panel
- PRE/POST EQ (for line out) switch on rear panel
- GROUND LIFT switch on rear panel
- MUTE SWITCH
- MASTER VOLUME
EQUALIZATION
- LOW: center frequency 68 Hz; level: ±16 dB
- MID LOW: center frequency 360 Hz; level: ±16 dB
- MID HIGH: center frequency 800 Hz; level: ±16 dB
- HIGH: center frequency 10 kHz; level: ±16 dB
- OLD SCHOOL: max cut range: 250 Hz – 20 kHz
- 3 WAY SWITCH: flat/scooped-mid/FSW
OUTPUTS
- SEND EFFECTS: unbalanced, max. voltage 20 Vpp
- TUNER OUT: unbalanced, max. voltage 2 Vpp
- LINE OUT balanced XLR, max. voltage 20 Vpp
- SPEAKER OUT: speakon/1/4” combo, 1/4”* OTHERS
- BI-BAND LIMITER
- FOOTSWITCH (OPTIONAL): FLAT/SCOOPED-MID
OUTPUT POWER
- 500W RMS @ 4 ohm
- 300W RMS @ 8 ohm
POWER REQUIREMENT: 100V; 120V; 230V; 240V 50/60Hz (Voltage is factory preset according to region of sale)
SPEAKER: 2×10″
TWEETER: piezo
BASS PORT: front
IMPEDANCE: 8 ohms
SENSITIVITY: 101 dB SPL
SPEAKER POWER HANDLING: 400W RMS (AES Standard)
FREQUENCY RESPONSE: 40 Hz to 18 kHz
CROSSOVER FREQUENCY: 3.5 kHz
WEIGHT: 37.7 lbs / 17.1 Kg
WIDTH: 23.03 in. / 58.5 cm
HEIGHT: 18.5 in. / 47 cm
DEPTH: 18.7 in. / 47.5 cm
Additional Information
| Manufacturer | MARKBASS |
|---|---|
| Model | CMD102P IV |
