| Keyboard |
88 weighted keys with Ivory Touch key surfaces Responsive Hammer II (RHII) action with Let-Of |
|
| Sound Source | Progressive Harmonic Imaging™ (PHI), 88-key piano sampling | |
| Internal Sounds | 32 voices (PIANO1, PIANO2, E.PIANO, ORGAN, HARPSI/MALLETS, STRINGS/CHOIR, BASS) | |
| Polyphony | max. 256 notes | |
| Keyboard Modes | Dual Mode, Split Mode, Four Hands Mode (Volume/Balance adjustable) | |
| Reverb | Type: | Room, Lounge, Small Hall, Concert Hall, Live Hall, Cathedral |
| Parameters: | Reverb Depth, Reverb Time | |
| Effects | Type: |
Stereo Delay, Ping Delay, Triple Delay, Chorus, Classic
Chorus, Tremolo, Classic Tremolo, Auto Pan, Classic Auto Pan, Phaser, Rotary. Combination eff ects x 4 |
| Parameters: | Dry/Wet, Time, Speed, Feedback, High Damp, Depth (Parameters dependent on eff ect type) | |
| Amp Simulator | Type: | S.Case I, S.Case II, L.Cabinet |
| Parameters: | Drive, Level, EQ Low, EQ High | |
| Virtual Technician | Touch Curve: | Light+, Light, Normal, Heavy, Heavy+, Off (Constant), User 1, User 2 |
| Voicing: | Normal, Mellow 1, Mellow 2 , Dynamic, Bright 1, Bright 2 | |
| Resonance, Noise & Effects: |
String Resonance, Damper Resonance, Damper Noise, Fall-back
Noise, Key-off Eff ect, Hammer Delay |
|
| Temperament: |
Equal (Piano), Pure Major, Pure minor, Pythagorean,
Meantone, Werckmeister, Kirnberger, Equal (Flat), Equal (Stretch), User, Stretch Tuning, Key of Temperament |
|
| Internal Recorder | 10 song, 2 track recorder – approximately 90,000 note memory capacity | |
| USB Functions | Playback: | MP3, WAV, SMF |
| Record: | MP3, WAV | |
| Other: |
Convert Song to Audio, Load Internal Song, Save Internal
Song, Save SMF Song, Load Registration, Save Registration, Rename File, Delete File, Format USB |
|
| Metronome | 1/4, 2/4, 3/4, 4/4, 5/4, 3/8, 6/8, 7/8, 9/8, 12/8 (Volume/Tempo adjustable) | |
| Rhythm Section | Styles: | 100 rhythms (x 2 variations), 4-part accompaniment, 100 preset chord sequences |
| Settings: | Rhythm Volume, Auto Fill-in, One Finger Ad-lib, ACC Mode, Preset Chord, Rhythm Parts Select | |
| Demo Songs | Main demo song, Rhythm Section demo song, 25 sound demo songs | |
| Other Functions |
Key/Song Transpose, Equaliser (incl. User EQ), Wall EQ,
Speaker Volume, Phones Volume, Line Out Volume, Audio Recorder Gain, Tuning, Damper Hold, Four Hands, User Memory, Factory Reset, Lower Octave Shift, Lower Pedal On/Off , Split Balance, Layer Octave Shift, Layer Dynamics, Dual Balance, MIDI Channel, Send PGM#, Local Control, Transmit PGM#, Multi-timbral Mode, Channel Mute, Auto Power Off , Speakers On/Of |
|
| Display | 16 x 2 characters LCD | |
| Jacks |
MIDI (IN/OUT), USB to Host, USB to Device, LINE IN STEREO,
LINE OUT (L/MONO, R), DAMPER (for F-10H), DAMPER/SOFT (for F-20), PEDAL (for F-301), Headphones x 2 |
|
| Speaker System | Speakers: | (8 x 12 cm) x 2 |
| Output Power: | 15 W x 2 | |
| Power Consumption | 35 W | |
| Dimensions | 1362 (W) x 361 (D) x 149 (H) mm / 54" (W) x 14 ½ " (D) x 6" (H) | |
| Weight | 22.0 kg / 49 lbs. |
Additional Information
| Manufacturer | KAWAI |
|---|---|
| Model | ES7SETBK |
