BOSS Octave OC5

Fusing classic BOSS octave tones with the latest tracking technologies, the BOSS OC-5 sets a new standard in octave pedal performance. Vintage mode provides a spot-on recreation of the legendary mono OC-2 from 1982, while Poly mode offers numerous enhancements for extended-range playing. And with the addition of an octave-up feature, a span of three octaves is now available for creative exploration. From fat, low mono sounds to octave-shifted chords and more, the OC-5 delivers the widest range, finest sound quality, and best playability in any octave stomp to date.

199,00 €

Availability: In stock

Manufacturer: BOSS

Model: OC5

SKU: INV07256

In stock

Tech Specs

  • Pedal Type:Guitar/Bass Octave
  • Effects:Octave-up, Octave-down, Poly Chord Mode, Vintage Mode
  • Inputs:1 x 1/4"
  • Outputs:1 x 1/4" (main out), 1 x 1/4" (direct out)
  • Bypass Switching:Buffered
  • Power Source:9V DC power supply required (sold separately)
  • Power Usage:55mA
  • Batteries:1 x 9V
  • Height:2.32"
  • Width:2.87"
  • Depth:5.07"
  • Weight:0.97 lbs.
  • Manufacturer Part Number:OC-5

SPECIFICATIONSNominal Input Level-20 dBuInput Impedance1 M ohmNominal Output Level-20 dBuOutput Impedance1 k ohmRecommended Load Impedance10 k ohms or greaterBypassBuffered bypassControlsPedal switch, GUITAR/BASS switch, VINTAGE/POLY switch, DIRECT LEVEL knob, +1OCT knob, -1OCT knob, -2OCT/RANGE knobIndicatorCHECK indicator (Serves also as battery check indicator)ConnectorsINPUT jack: 1/4-inch phone type
OUTPUT jack: 1/4-inch phone type
DIRECT OUT jack: 1/4-inch phone type
DC IN jackPower SupplyAlkaline battery (9 V, 6LR61 or 6LF22)
AC adaptor (PSA series: sold separately)Current Draw55 mAExpected battery life under continuous useAlkaline: Approx. 7 hours*These figures will vary depending on the actual conditions of use.AccessoriesOwner's manual
Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information")
Alkaline battery (9 V, 6LR61)Options (sold separately)AC adaptor: PSA seriesSIZE AND WEIGHTWidth73 mm
2-7/8 inchesDepth129 mm
5-1/8 inchesHeight59 mm
2-3/8 inchesWeight (including battery)440 g
1 lb

Additional Information

Manufacturer BOSS
Model OC5
