Body
- Body: Mahogany
- Body Back: Mahogany
- Body Finish: Polyester Satin Matte
- Body Material: Mahogany
- Body Shape: Modified Telecaster®
- Body Sides: Mahogany
- Body Style: Modified Telecaster
- Body Top: Solid Mahogany
- Bracing: Transverse
- Cutaway: Yes
- Purfling: Tortoiseshell
- Rosette: Tortoiseshell
- Sound Hole: WaterFall Sound Port
Electronics
- Controls: Master Volume, "Blend" Knob, 5-Way Switch
- Special Electronics: 3-pickup configuration: Under-Saddle Piezo/Internal Body Sensor/N4 Magnetic
Hardware
- Bridge: Modern Asymmetrical
- Bridge Pins: Graph Tech® TUSQ®
- Hardware Finish: Chrome
- Pickguard: None
- Strap Buttons: American Series
- Strings: Fender® Dura-Tone® 860CL Coated Phosphor Bronze (.011-.052 Gauges), PN 0730860405
- Tuning Machines: Fender® Standard Cast/Sealed Staggered
Measurements
- Body Depth: 1.75" (44.45 mm)
- Body Length: 16.54" (420 mm)
- Fret Size: Narrow Tall
- Scale Length: 25.5" (64.77 cm)
Neck
- Fingerboard Material: Ebony
- Fingerboard Radius: 12" (305 mm)
- Neck Finish: Satin Urethane
- Neck Material: Mahogany
- Neck Shape: Modern "Deep C"
- Number of Frets: 22
- Nut Material: Graph Tech® TUSQ®
- Nut Width: 1.6875" (42.86 mm)
- Position Inlays: White Dot
- String Nut: Graph Tech® TUSQ®
- Truss Rod: Bi-Flex™
- Truss Rod Nut: 1/8" American Series
Additional Information
| Manufacturer | FENDER |
|---|---|
| Model | 0972013137 |
