| Size/Weight | Dimensions | Width | 1,357 mm [53-7/16"] |
|---|---|---|---|
| Height | 849 mm [33-7/16"] (With music rest raised: 1,003 mm [39-1/2"]) | ||
| Depth | 422 mm [16-5/8"] | ||
| Weight | Weight | 42 kg [92 lbs., 10 oz.] | |
| Dimensions of Packing Box | W x H x D | 1,421 mm x 468 mm x 544 mm [55-15/16" x 18-7/16" x 21-7/16"] | |
| Control Interface | Keyboard | Number of Keys | 88 |
| Type | GrandTouch-E™ Keyboard: synthetic ebony and ivory key tops, escapement | ||
| Touch Sensitivity | Hard, Medium, Soft, Fixed | ||
| Pedal | Number of Pedals | 3: Damper (with Half-pedal function), Sostenuto, Soft | |
| Panel | Language | English | |
| Cabinet | Key Cover Style | Sliding | |
| Music Rest | Yes (with music braces) | ||
| Voices | Tone Generator | Piano Sound | Yamaha CFX |
| Virtual Resonance Modeling (VRM) | Yes (VRM Lite) | ||
| Polyphony | Number of Polyphony (Max.) | 192 | |
| Preset | Number of Voices | 10 | |
| Effects | Types | Reverb | 4 types |
| Intelligent Acoustic Control (IAC) | Yes | ||
| Stereophonic Optimizer | Yes | ||
| Functions | Dual | Yes | |
| Duo | Yes | ||
| Songs | Preset | Number of Preset Songs | 10 Voice Demo, 50 Classics, 303 Lesson Songs |
| MIDI Recording | Number of Songs | 1 | |
| Number of Tracks | 2 | ||
| Data Capacity | Approx. 150 KB/Song (approx. 11,000 notes) | ||
| Compatible Data Format | Playback | SMF (Format 0, Format 1) | |
| Recording | SMF (Format 0) | ||
| Functions | Overall Controls | Metronome | Yes |
| Tempo Range | 5 – 280 | ||
| Transpose | −6 – 0 – +6 | ||
| Tuning | 414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments) | ||
| USB Audio Interface | 44.1 kHz, 24 bit, stereo | ||
| Bluetooth | Audio, MIDI (varies by area) | ||
| Storage and Connectivity | Connectivity | Headphones | Standard stereo phone jack (× 2) |
| USB TO HOST | Type B | ||
| DC IN | 16 V | ||
| Amplifiers and Speakers | Amplifiers | 20 W × 2 | |
| Speakers | 12 cm with diffuser × 2 | ||
| Power Supply | AC Adaptor | PA-300C | |
| Power Consumption | 13 W (When using PA-300C AC adaptor) | ||
| Auto Power Off | Yes | ||
| Accessories | Included Accessories | Owner’s Manual, “50 Classical Music Masterpieces” Music Book, Online Member Product Registration, AC adaptor | |
| Separately Sold Accessories | Headphones (HPH-150, HPH-100, HPH-50), Pedal unit (FC35), AC adaptor (PA-300C) | ||
| Manufacturer | YAMAHA |
|---|---|
| Model | YDP166B |
