Size/Weight
|
|
Dimensions
|
Width
|
1,350 mm [53-1/8"] Polished finish: 1,353 mm [53-1/4"]
|
|
Height
|
849 mm [33-7/16"] (with music rest raised: 1,003 mm
[39-1/2"]) Polished finish: 851 mm [33-1/2"] (with music
rest raised: 1,005 mm [39-9/16"])
|
|
Depth
|
411 mm [16-3/16"] Polished finish: 411 mm [16-3/16"]
|
|
Weight
|
Weight
|
45 kg [99 lb, 3 oz] Polished finish: 47 kg [103 lb, 10 oz]
|
|
Dimensions of Packing Box
|
W x H x D
|
-
|
|
Control Interface
|
|
Keyboard
|
Number of Keys
|
88
|
|
Type
|
GrandTouch-S™ keyboard: synthetic ebony and ivory key tops,
escapement
|
|
Touch Sensitivity
|
Hard, Medium, Soft, Fixed
|
|
88-key Linear Graded Hammers
|
-
|
|
Counterweight
|
-
|
|
Pedal
|
Number of Pedals
|
3: Damper (with half-pedal function), Sostenuto, Soft
|
|
GrandTouch Pedals
|
Yes
|
|
Assignable Functions
|
-
|
|
Display
|
Type
|
-
|
|
Language
|
-
|
|
Panel
|
Type
|
-
|
|
Language
|
English
|
|
Cabinet
|
|
Key Cover Style
|
Sliding
|
|
Music Rest
|
Yes
|
|
Music Braces
|
Yes
|
|
Voices
|
|
Tone Generator
|
Piano Sound
|
Yamaha CFX, Bösendorfer Imperial
|
|
Binaural Sampling
|
Yes (“CFX Grand” only)
|
|
Virtual Resonance Modeling (VRM)
|
Yes
|
|
Grand Expression Modeling
|
Yes
|
|
Polyphony
|
Number of Polyphony (Max.)
|
256
|
|
Preset
|
Number of Voices
|
10
|
|
Compatibility
|
-
|
|
Effects
|
|
Types
|
Reverb
|
4 types
|
|
Chorus
|
-
|
|
Brilliance
|
-
|
|
Insertion Effect
|
-
|
|
Intelligent Acoustic Control (IAC)
|
Yes
|
|
Stereophonic Optimizer
|
Yes
|
|
Functions
|
Dual/Layers
|
Yes
|
|
Split
|
-
|
|
Duo
|
Yes
|
|
Songs
|
|
Preset
|
Number of Preset Songs
|
10 Voice Demo + 50 Classics + 303 Lesson Songs
|
|
MIDI Recording
|
Number of Songs
|
1
|
|
Number of Tracks
|
2
|
|
Data Capacity
|
Approx. 250 KB/Song (approx. 11,000 notes)
|
|
Audio Recording (USB flash drive)
|
Recording Time (max.)
|
-
|
|
Compatible Data Format
|
Playback
|
SMF (Format 0, Format 1)
|
|
Recording
|
SMF (Format 0)
|
|
Functions
|
|
Piano Room
|
-
|
|
Rhythm
|
Number of Rhythms
|
-
|
|
Overall Controls
|
Metronome
|
Yes
|
|
Tempo Range
|
5 – 280
|
|
Transpose
|
−6 – 0 – +6
|
|
Tuning
|
414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments)
|
|
Scale Type
|
-
|
|
USB Audio Interface
|
44.1 kHz, 24 bit, stereo
|
|
Bluetooth
|
Audio, MIDI (varies by area)
|
|
Storage and Connectivity
|
|
Storage
|
Internal Memory
|
-
|
|
External Drives
|
-
|
|
Connectivity
|
Headphones
|
Standard stereo phone jack (× 2)
|
|
AUX IN
|
-
|
|
AUX OUT
|
-
|
|
USB TO DEVICE
|
-
|
|
USB TO HOST
|
Type B
|
|
DC IN
|
16 V
|
|
Amplifiers and Speakers
|
|
Amplifiers
|
20 W × 2
|
|
Speakers
|
12 cm with diffuser × 2
|
|
Power Supply
|
|
AC Adaptor
|
PA-300C
|
|
Power Consumption
|
12 W (When using PA-300C AC adaptor)
|
|
Auto Power Off
|
Yes
|
|
Accessories
|
|
Included Accessories
|
Owner’s Manual, “50 Classical Music Masterpieces” Music
Book, Online Member Product Registration, Power cord*/AC
adaptor* (PA-300C) *Varies by area
|
|
Separately Sold Accessories
|
Headphones (HPH-150, HPH-100, HPH-50), Pedal unit (FC35),
AC adaptor (PA-300C)
|
