BODY
- Body Style: Les Paul
- Body Shape: Les Paul
- Body Material: Mahogany
- Top: Maple
- Binding: Cream
- Body Finish: Gloss Nitrocellulose Lacquer
- Weight Relief: None
NECK
- Profile: Rounded "C"
- Scale Length: 628.65 mm / 24.75 in
- Fingerboard Material: Indian Rosewood
- Fingerboard Radius: 304.8 mm / 12 in
- Neck Material: Mahogany
- Fret Count: 22
- Frets: Medium Jumbo
- Nut Material: Graph Tech
- Nut Width: 43.053 mm / 1.695 in
- Inlays: Acrylic Trapezoids
- Joint: Glued in
HARDWARE
- Finish: Chrome
- Bridge: Tune-O-Matic
- Tailpiece: Aluminum Stop Bar
- Tuning Machines: Vintage Keystone
- Pickguard: Cream
- Truss Rod: Adjustable
- Truss Rod Cover: 2-ply Bell, "Deluxe" Hot Stamp
- Control Knobs: Gold Top Hats with Silver Inserts
- Switch Tip: Cream
- Switch washer: Cream
- Jack Plate Cover: Chrome
- Control Covers: Black
- Strap Buttons: 2 - Bottom and Shoulder
- Mounting Rings: Cream
- Pickup Covers: Chrome
ELECTRONICS
- Neck Pickup: Mini Humbucker
- Bridge Pickup: Mini Humbucker
- Controls: 2 Volume, 2 Tone, (Hand-wired with Orange Drop Capacitors)
- Pickup Selector: 3-way Toggle Switch
- Output Jack: 1/4"
- MISCELLANEOUS
- Strings Gauge: .010, .013, .017, .026, .036, .046
- Case: Hardshell Case (940-18163)
Additional Information
| Manufacturer | GIBSON |
|---|---|
| Model | LPDX00GTCH1 |
