Color/Finish
|
|
Body
|
Color
|
Black
|
|
Size/Weight
|
|
Dimensions
|
Width
|
1,017 mm (40")
|
|
Height
|
139 mm (5-1/2")
|
|
Depth
|
431 mm (17")
|
|
Weight
|
Weight
|
11.6 kg (25.57 lbs.)
|
|
Packing Box
|
Width
|
1,174 mm (46-3/16")
|
|
Height
|
246 mm (9-11/16")
|
|
Depth
|
511 mm (20-1/8")
|
|
Control Interface
|
|
Keyboard
|
Number of Keys
|
61
|
|
Type
|
Organ (FSB), Initial Touch
|
|
Touch Response
|
Normal, Soft1, Soft2, Hard1, Hard2
|
|
Other Controllers
|
Joystick
|
Yes (Assignable)
|
|
Control Knobs
|
2 (Assignable)
|
|
Assignable Buttons
|
6 + 2 (With LED Indicator)
|
|
Pitch Bend
|
-
|
|
Modulation
|
-
|
|
Display
|
Type
|
TFT Color Wide VGA LCD
|
|
Size
|
800 x 480 dots (7 inch)
|
|
Touch Screen
|
Yes
|
|
Color
|
Yes
|
|
Language
|
English, German, French, Spanish, Italian, Chinese
|
|
Panel
|
Language
|
English, Chinese
|
|
Voices
|
|
Tone Generation
|
Tone Generating Technology
|
AWM Stereo Sampling
|
|
Polyphony
|
Number of Polyphony (Max.)
|
128
|
|
Preset
|
Number of Voices
|
1,377 Voices + 56 Drum/SFX Kits + 480 XG Voices
|
|
Featured Voices
|
9 S.Articulation+, 252 S.Articulation, 55 OrganFlutes, 54
MegaVoice
|
|
Expandability
|
Expansion Voice
|
Yes (approx. 1 GB)
|
|
Editing
|
-
|
|
Compatibility
|
|
XG, GM, GM2 (for Song Playback）
|
|
XG
|
-
|
|
GS
|
-
|
|
GM
|
-
|
|
GM2
|
-
|
|
Part
|
Right1, Right2, Right3, Left
|
|
Effects
|
|
Types
|
Reverb
|
59 Preset + 30 User
|
|
Chorus
|
106 Preset + 30 User
|
|
DSP
|
322 Preset + 30 User
|
|
Insertion Effect
|
1-8: 322 Preset + 30 User
|
|
Master Compressor
|
5 Preset + 30 User
|
|
Master EQ
|
5 Preset + 30 User
|
|
Part EQ
|
28 Parts
|
|
Others
|
-
|
|
Arpeggio
|
-
|
|
Vocal Harmony
|
Number of Presets
|
-
|
|
Number of User Settings
|
-
|
|
Accompaniment Styles
|
|
Preset
|
Number of Preset Styles
|
450
|
|
Featured Styles
|
410 Pro Styles, 37 Session Styles, 3 Free Play Styles
|
|
Fingering
|
Single, Fingered, OnBass, Multi, AI Fingered, Full / AI
Full, Smart Chord
|
|
Style Control
|
INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3
|
|
Compatibility
|
Style File Format, Style File Format GE
|
|
Expandability
|
Expansion Style
|
Yes (Internal Memory)
|
|
Expansion Audio Style
|
-
|
|
Other Features
|
Chord Looper
|
Yes
|
|
Style Section Reset
|
Yes
|
|
Style Section Change Timing
|
Yes
|
|
Style Section Time Signature
|
Yes (per Section)
|
|
Style Dynamics Control
|
Yes (with knobs / pedal)
|
|
One Touch Setting (OTS)
|
4 for each Style
|
|
Unison & Accent
|
-
|
|
Songs
|
|
Preset
|
Number of Preset Songs
|
1 Demo Song, 2 Preset Songs
|
|
Recording
|
Number of Songs
|
Unlimited (depending on USB flash memory capacity)
|
|
Number of Tracks
|
16
|
|
Data Capacity
|
Approx. 3 MB/Song
|
|
Recording Function
|
Quick Recording, Multi Recording, Step Recording
|
|
Compatible Data Format
|
Playback
|
SMF (Format 0 & 1), XF
|
|
Recording
|
SMF (Format 0)
|
|
Multi Pads
|
|
Preset
|
Number of Multi Pad Banks
|
349 banks x 4 Pads
|
|
Audio
|
Audio Link
|
Yes
|
|
Functions
|
|
Voices
|
Harmony/Echo
|
Yes (with Arpeggio)
|
|
Panel Sustain
|
Yes
|
|
Mono/Poly
|
Yes (w/ Legato, Xfd (improved), VeloToPrtTime,
FastPlayingPortamento, Velocity Limit)
|
|
Voice Information
|
Yes
|
|
Styles
|
Style Creator
|
Yes
|
|
OTS Information
|
Yes
|
|
Songs
|
Song Creator
|
Yes
|
|
Score Display Function
|
Yes
|
|
Lyrics Display Function
|
Yes
|
|
Multi Pads
|
Multi Pad Creator
|
Yes
|
|
Registration
|
Number of Buttons
|
8
|
|
Control
|
Registration Sequence, Freeze
|
|
Playlist
|
Number of Records
|
2,500 (max.) Records per Playlist file (add search/sort
function improved)
|
|
Search
|
Registration Bank
|
|
Audio Recorder/Player
|
Recording Time (max.)
|
80 minutes/Song
|
|
Recording
|
.wav (WAV format: 44.1 kHz sample rate, 16 bit resolution,
stereo), .mp3 (44.1 kHz sample rate,128/256/320 kbps,
mono/stereo)
|
|
Playback
|
.wav (WAV format: 44.1 kHz sample rate, 16 bit resolution,
stereo), .mp3 (MPEG-1 Audio Layer-3: 44.1/48.0 kHz sample
rate, 64-320 kbps and variable bit rate, mono/stereo)
|
|
Time Stretch
|
Yes
|
|
Pitch Shift
|
Yes
|
|
Vocal Cancel
|
Yes
|
|
Lyrics Display Function
|
-
|
|
Demo/Help
|
Demonstration
|
Yes
|
|
Overall Controls
|
Metronome
|
Yes
|
|
Tempo Range
|
5 - 500, Tap Tempo
|
|
Transpose
|
-12 – 0 – +12
|
|
Tuning
|
414.8 – 440 – 466.8 Hz
|
|
Octave Button
|
-3 -0- 3
|
|
Scale Type
|
9 Preset
|
|
Sub Scale Setting
|
Yes
|
|
Miscellaneous
|
Direct Access
|
Yes
|
|
Text Display Function
|
Yes
|
|
Wallpaper Customization
|
Yes
|
|
Display Out
|
-
|
|
Bluetooth
|
-
|
|
Lesson/Guide
|
Lesson/Guide
|
-
|
|
Storage and Connectivity
|
|
Storage
|
Internal Memory
|
Approx. 1 GB max.
|
|
External Drives
|
USB Flash Memory (via USB to DEVICE)
|
|
Connectivity
|
Headphones
|
Yes
|
|
Microphone
|
Mic/Guitar
|
|
MIDI
|
IN/OUT
|
|
AUX IN
|
Stereo mini
|
|
LINE OUT
|
L / L+R, R
|
|
DIGITAL OUT
|
-
|
|
FOOT PEDAL
|
Assignable, Sw or Vol x2
|
|
USB TO DEVICE
|
USB 2.0 ×1
|
|
USB TO HOST
|
USB 2.0 ×1
|
|
Wireless LAN
|
-
|
|
Amplifiers and Speakers
|
|
Amplifiers
|
15 W x2
|
|
Speakers
|
[13 cm + 5 cm ] x2
|
|
Power Supply
|
|
Power Supply
|
PA-300C or an equivalent recommended by Yamaha
|
|
Power Consumption
|
21 W
|
|
Auto Power Off Function
|
Yes
|
|
Accessories
|
|
Included Accessories
|
Owner's Manual, Music Rest, AC Adaptor (may not be included
depending on your area. Check with your Yamaha dealer.)
|
